| Capacitance range |
0.001μF to 10μF |
| Capacitance Tolerance |
±20%；±10%; ±5% |
| Rated AC voltage |
300 VAC； 50 Hz to 60 Hz |
| Allowable DC voltage |
800 VDC at 85°C
630 VDC at 100°C |
| Climate test class (according to IEC 60068-1) |
40/100/21/C, product volume≤1750mm3 |
| Maximum use temperature |
C≤470nF：100°C (less than 1000 hours at 110°C)
C > 470 nF：100°C |
| Wire |
Tinned copper wire |
| Guideline |
UL 60384-14
CSA-E384-14
CQC |
| Dielectric |
Polypropylene film |
| Electrode |
Metallized film |
| Package |
Plastic housing, epoxy sealed, flame retardant UL
rated 94 V-0 |
| Mark |
Capacity value; Tolerance; Rated voltage;
Manufacturer's model number;
Dielectric Material Code; Manufacturer's Marking;
Safety Certification |
| Dimensions are in (mm) |
